Facilities
- Geotechnical Engineering Laboratory
- CME 55 Drill Rigs
- Portable Drill Rigs
- PDA Equipment
- Nuclear Densometers
- PIT Equipment
- Digital Inclinometer
New
- Two Minimate Plus™ monitors are equipped with three geophones and one linear microphone and the Blastware™ software. This new addition to our already wide range of equipment allows us to monitor vibrations from traffic, pile driving, under water blast monitoring, demolition activity monitoring, construction activity, blast monitoring for compliance and near field blast analysis.
- 4point light 10W Electrical resistivity meter by Lippmann Geophysical Instruments and the WinSev 6 inversion software. It can determine electrical resistivity using either the Wenner, Schlumberger and Pole-Pole arrays. It has been used on several projects to assist in the determination of failure planes for landslips.
Minimate Plus™ monitor with linear micophone and triaxial geophone |
|
4point light 10W electrical resistivity meter |
|
Close view of he 4point light 10W electrical resistivity meter |
|
In addition to these facilities, below are some photos of our equipment used for analysis and testing:
Drilling accomplished with Hollow Stem Augering – CME 55 Drill Rig |
|
Drilling accomplished with Hollow Stem Augering – Mobil B 53 Drill Rig |
|
Pile Driving Analyzer (PDA) PAK |
|
Testing on a Steel Pipe Pile |
|
Strain and accelerometer gages attached to octagonal precast prestressed concrete pile prior to PDA test |
|
PDA Test being carried out on a Marine Pile |
|
|
|
|
|
|
|
